MokerLink 5 Port 2.5G PoE Switch, 5 x 2.5GBASE-T Ports, 4 Port PoE IEEE802.3af/at 65W, Compatible with 10/100/1000Mbps, Unmanaged Fanless Wall Mountable Network Switch

4 x 2.5G PoE Ports and 1 x 2.5G Uplink Port, Port 2-4 support IEEE802.3af/at(Max 30W), Port 1 support IEEE802.3bt(max 60W), Unmanaged Plug and Play, durable metal casing, fanless design, Widely used for 4K video, gaming PC, NAS, PCIe Adapter, Server, WiFi 6 AP and more

$199.99 Price drop reminder
  • Brand: MokerLink
  • Product Code: POE-2G041G
  • Availability: In Stock

Total $199.99
MokerLink 5 port 2.5G PoE switch upgrading networks by providing a more reliable, stable, seamless network and easily multiplying the network speed by 2.5 times. It provides 4*10M/100M/1G/2.5G PoE ports + 1*10M/100M/1G/2.5G uplink port with line speed forwarding capability per port. The PoE power port can automatically detect and power the powered devices that comply with the IEEE 802.3af or IEEE802.3at standards. The non-PoE device intelligently detects no power and only transmits data.
Key Features
  • Up to 80G backplane bandwidth, 12M cache, 28.8M packet forwarding rate, and support 12K giant frame transmission.
  • Provide 4* 10M/100M/1G/2.5Gbps PoE ports + 1* 10M/100M/1G/2.5Gbps Uplink port.
  • PoE port 1 support IEEE802.3af/at/bt (PoE++), Max output 60W.
  • PoE port(2-4) support IEEE802.3af/at (PoE+), Max output 30W.
  • Each port supports MDI/MDIX automatic flip and duplex/rate self negotiation.
  • Support IEEE 802.3x full duplex flow control and backpressure half duplex flow control.
Application Environment
With 2.5 Gigabit speed, the POE-2G041G brings high-flexibility and high-bandwidth connectivity to WIFI6 AP, router, servers, workstations and other attached devices. It enables you to save time when transferring large files. 12K jumbo frames are also supported to improve network utilization in large files transfer.
Full 2.5G Port
5 port 2.5g PoE switch features non-blocking wire-speed architecture with 80Gbps switching capacity for maximum data throughput. It supports IEEE 802.3x flow control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission. An 8K MAC address table provides scalability for even the largest networks.
IEEE802.3af/at/bt(PoE++) Support
Compatible with IEEE802.3af/at/bt standard, PoE switch determines and delivers the exact power supply to your devices with up to 65W. Port 1 support IEEE802.3bt(Max 60w), Port 2-4 support IEEE802.3at(Max 30W).
Plug and Play
This 5 port 2.5G PoE switch support installation plug and play. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10/100/1000Mbps) and intelligently adjusts for compatibility and optimal performance.
Lighting Protection
The 5 port 2.5g PoE switch fetures with 6KV power port surge protection and 2KV network port surge protection can adapt to harsh outdoor environment and ensure the reliability of the uninterrupted network system.
Fanless Quiet Design
Fanless design improve energy efficiency and lower financial cost. Passive cooling achieves high levels of natural convection and heat dissipation by utilizing a heat spreader or a heat sink to maximize the radiation and convection heat transfer modes, It is a solution for switches to maintain optimal operating temperatures without causing much noise.
Compact Size
The compact design makes these sensors interesting for room critical applications.

Ask Question About Product

Note: HTML is not translated!
Ethernet Switch Hardware Specifications
Product ModelPOE-2G041G
Product NameMokerLink 5 Port 2.5G PoE Switch
Ethernet Port4*10M/100M/1G/2.5Gbps PoE port + 1*10M/100M/1G/2.5Gbps UpLInk port
Switching Capacity80Gbps
Packet Buffer12M
MAC Address16K
Jumbo Frame12Kb
Transfer ModeStore and forward
Network protocol IEEE 802.3/U、IEEE 802.3ab、IEEE 802.3bz、IEEE 802.3x
PoE ProtocolPort 1 supports IEEE802at/at/poe++/BT(MAX_90W), port 2-4 supports IEE802.3at/at(MAX_30W)
PoE PinPort1: 1/2(+),3/6(-); 4/5(+),7/8(-) Port2-4:1/2(+),3/6(-);
PoE Power Budget65W
Industry StandardCE mark, commercial;CE/LVD EN60950; FCC Part 15 Class B;RoHS;
Transmission Distance10BASE-T: Cat5 or later UTP(150 meter)100BASE-TX: Cat5 or later UTP(150 meter)2500/1000BASE-TX: Cat6 or later UTP(150 meter)
Lighting Protection6KV 8/20us;IP30
Working EnvironmentWorking Temperature: -10~55°CStorage Temperature: -40~75°CWorking Humidity: 10%~90%,non-condensingStorage Temperature: 5%~90%,non-condensingWorking Height: Maximum10,000 feetStorage heigh: Maximum 10,000 feet
LED IndicatorPWR:Power LED Port:10M//100 LED(Right green); 1G LED(Left Green); 2.5G LED(Left orange) PoE: PoE on led
Structure SizeProduct Dimension (L*W*H): 60mm*115mm*33mmPackage Dimension (L*W*H): 305mm*205mm*55mmN.W: 0.6kgG.W: 1.0kg
InstallationDesktop/Wall Mount
ShellBlack Color, Metal Shell
Power VoltageAdaptor: MAX 65W (AC100-240V 50/60HZ MAX 1.5A)
Package ListSwitch 1 pcs, Power cord 1 pcs, User manual 1 pc
  • All(0)
  • Good(0)
  • Fair(0)
  • Poor(0)
  • Image(0)
Name Size Date Added
2.5G Switch Series Quick Start Guide 628.31KB 11/12/2022 17:43:18
