MokerLink 48 Port PoE Gigabit Switch, 2 Gigabit SFP, IEEE802.3af/at/bt 400W, Metal Rackmount Unmanaged Plug and Play Ethernet Switch
48 gigabit PoE ports and 2 gigabit SFP ports, IEEE802.3af/at/bt 400W, Unmanaged Plug and Play, Durable Metal housing, fanless silent, widely used in home/business/data PoE network
- Brand: MokerLink
- Product Code: POE-G482GS
- Availability: In Stock
POE-G480G is all gigabit unmanaged enterprise PoE ethernet switch . It is designed to optimize and enhance the design for enterprise customers and has higher reliability. Provided 48*10/100/ 1000M PoE ports with line speed forwarding capability for each port. This series of switches have good network adaptability for security monitoring, diskless startup and wireless networking applications.
- Provide strong power, use 500MHz CPU, 4.1M cache, 80.64M packet forwarding rate,.
- Support 9K mega frame transmission.
- Provide 48*10/100/ 1000M PoE ports which can realize line speed forwarding.
- Each port supports MDI/MDIX automatic flip and duplex rate self negotiation.
- Support IEEE 802.3x full duplex flow control and backpressure half duplex flow control.
Full Gigabit Port
48 port gigabit PoE switch features non-blocking wire-speed architecture with 112Gbps switching capacity for maximum data throughput. It supports IEEE 802.3x flow control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission. An 8K MAC address table provides scalability for even the largest networks.
This unmanaged PoE switch compatible with IEEE 802.3af/at/bt protocol, PoE switch determines and delivers the exact power supply to your devices with up to 90W power output. If a device not IEEE802.3af/at/bt compliant, only network data will be transmitted through the LAN cable to avoid from being damaged by incorrect power sending.
48 port gigabit PoE switch support 2 x Uplink SFP ports, The switch's sfp port 49-50 use fiber cable to connect wired network segments throughout buildings or across campuses extending beyond the limitations of Ethernet cabling.
The 48 port gigabit PoE switch fetures with 6KV power port surge protection and 2KV network port surge protection can adapt to harsh outdoor environment and ensure the reliability of the uninterrupted network system.
The adjustable fan speed from min 0 up to max 4000rpm of the radiator according your overload, It is perfect for heat-exhaust and ventilation. When the fan speed is under 2400rpm, it is nearly no noisy.
Compact size shell make it ideal for desktops with limited space while it is also 19'' rackmountable. It includes all the necessary mounting hardware in the box.
Mick: Does it push the amount of power required by the device (e.g., 24 volts)?2022-12-10 23:15:17
Answer: This model is IEEE802.3 bt/at/af compliant which means that it can provide 44-57 volts and a current of 10-600mA, but it can\'t provide 24 volts.2022-12-10 23:18:17
Michael: Does this have the wattage to support 24 poe cameras and 24 poe aps?2022-12-10 23:14:47
Answer: Yes, this switch support 48 poe port ,but ensure that the maximum poe power consumption does not exceed 400W.2022-12-10 23:18:58
Ask Question About Product
|Ethernet Switch Hardware Specifications|
|Product Name||48 Port Gigabit PoE Switch with 2 SFP Ports|
|Ethernet Port||48*10/100/1000Base-TX PoE port + 2*1G SFP|
|Transfer Mode||Store and forward|
|Mean Time Between Failure||100000 hour|
|Network protocol||IEEE 802.3 IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x IEEE 802.3z 1000BASE-X IEEE 802.3af/at/PoE++/BT|
|PoE Protocol||Port1-Port2; Support IEEE802.3af/at/PoE+=/BT Port3-Port48; Support IEEE802.3af/at|
|PoE Pin||1/2 (+), 3/6(-)|
|PoE Power Budget||≤400W|
|Network Medium||10BASE-T ： Cat3,4,5 UTP(≤250 meter) 100BASE-TX ： Cat5 or later UTP(≤100 meter) 1000BASE-TX ： Cat6 or later UTP(≤1000 meter) 1000BASE-SX:62.5μm/50μm MMF(2m~550m) 1000BASE-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)|
|Transmission Distance||10BASE-T ： Cat3,4,5 UTP(≤250 meter) 100BASE-TX ： Cat5 or later UTP(≤100 meter) 1000BASE-TX ： Cat6 or later UTP(≤1000 meter)1000BASE-SX:62.5μm/50μm MMF(2m~550m)1000BASE-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)|
|Lighting Protection||3KV 8/20us, IP30|
|Working Environment||Operating Temperature/Humidity: -10～+55°C；5%～90% RH Non coagulation, Storage Temperature/Humidity -40～+75°C；5%～95% RH Non coagulation|
|LED Indicator||PWR:Power LED 1-50:(Link LED=10/100M Link、1000M=Gigabit Link)|
|Structure Size||Product size/Packing size(L*W*H): 440mm*290mm*45mm / 515mm*375mm*95mm, N.W/G.W(kg): 4.2kg/5kg|
|Power Voltage||Built-in power AC：100～240V 50-60Hz 7A(400W_9A)|
|Package List||Switch 1 pcs,Power cord 1 pcsUser manual 1 pc Brackets 1 pair|
