MokerLink 8 Port 2.5G Ethernet Managed Switch, 8 x 2.5GBASE-T Ports, Compatible with 10/100/1000Mbps, L2 Web Managed Fanless Network Switch
8x 2.5G ethernet ports, Web managed, L2 management function- such as VLAN, QoS, security, multicast, MAC address table, diagnosis, etc. With durable metal casing, fanless design lowers energy consumption, quiet no noise and stable operation, easy to Maintain, Widely used for various environments
- Brand: MokerLink
- Product Code: 2G080GM
- Availability: In Stock
- Up to 80G backplane bandwidth, 12M cache, 28.8M packet forwarding rate, and support 12K jumbo frame transmission.
- Provide 8*10M/100M/1000M/2.5G RJ45 ports for high-speed transmission.
- Each port supports MDI/MDIX automatic flip and duplex/rate self negotiation.
- Support IEEE 802.3x full duplex flow control and backpressure half duplex flow control.
- Support web GUI management, device/port status query and various configurations: such as VLAN, QoS, security, multicast, MAC address table, diagnosis, etc.
Full 2.5G Port
The 2G080GM features non-blocking wire-speed architecture with 80Gbps switching capacity for maximum data throughput. It supports IEEE 802.3x flow control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission. An 8K MAC address table provides scalability for even the largest networks.
This switch support IEEE802.1Q VLAN function, By segregating your networks without buying separate equipment for each, you can create virtual boundaries around business units to slow down or stop attacks for higher security.
Advanced QoS prioritize critical business traffic such as video conferencing, offering a lag-free network experience that helps the long-term customer and employee relationships.
Work with Existing Cabling
It can be deployed where extra bandwidth is demanded without costly, time-consuming re-cabling or equipment replacement costs.
The 8 port 2.5g switch fetures with 6KV power port surge protection and 2KV network port surge protection can adapt to harsh outdoor environment and ensure the reliability of the uninterrupted network system.
Fanless Quiet Design
Fanless design improve energy efficiency and lower financial cost. Passive cooling achieves high levels of natural convection and heat dissipation by utilizing a heat spreader or a heat sink to maximize the radiation and convection heat transfer modes, It is a solution for switches to maintain optimal operating temperatures without causing much noise.
The compact design makes these sensors interesting for room critical applications
Ask Question About Product
|Ethernet Switch Hardware Specifications|
|Product Name||8 Port 2.5G Web Managed Switch|
|Ethernet Port||8*10M/100M/1000M/2.5G RJ45 Port|
|CPU||MIPS-34Kc UP to 800MHZ CPU|
|Transfer Mode||Store and forward|
|Network protocol||IEEE 802.3/U、IEEE 802.3ab、IEEE 802.3bz、IEEE 802.3x|
|Network Medium||10BASE-T ： Cat3,4,5 UTP(≤250 meter) 100BASE-TX ： Cat5 or later UTP(150 meter) 2500/1000BASE-TX ：Cat6 or later UTP(150 meter)|
|Transmission Distance||10BASE-T: Cat5 or later UTP(150 meter)100BASE-TX: Cat5 or later UTP(150 meter)2500/1000BASE-TX: Cat6 or later UTP(150 meter)|
|Lighting Protection||6KV 8/20us;IP30|
|Working Environment||Working Temperature: -10~55°CStorage Temperature: -40~75°CWorking Humidity: 10%~90%，non-condensingStorage Temperature: 5%~90%，non-condensingWorking Height: Maximum10,000 feetStorage heigh: Maximum 10,000 feet|
|LED Indicator||PWR: Power LED Port: 10M/100M LED; 1G LED; 2.5G LED, SYS LED|
|Structure Size||Product Dimension (L*W*H): 223mm*103mm*28mmPackage Dimension (L*W*H): 305mm*205mm*55mmN.W: 0.8kgG.W: 1.2kg|
|Installation||Desktop and Wall Mount|
|Shell||Black Color, Metal Shell|
|Power Voltage||Adatpor: MAX 15W (AC 100-240V 50/60HZ MAX 0.3A)|
|Package List||Switch 1 pcs, Power cord 1 pcs, User manual 1 pc|
|Software Function||L2 Managed function, such as VLAN, QoS, security, multicast, MAC address table, diagnosis, etc.|
