The non-managed fiber media converter is designed with a switch controller and buffer memory that connects two types segments operation smoothly. The converter can be used as standalone type or as card type to the 2U 19” converter rack-mount chassis for centralized power management.
Data Rate: 10/100/1000Mbps.
Fiber Type: 550M/2KM for Multimode; 20/40/60/80/120KM for Single mode.
Optic Connector: SC(optional)/ST/FC/LC
Features:
1. Built-in efficient exchange kernel
2. Broadcasting filtration function, flow control, CRC error check.
3. Supports SPANNING TREE to conduct fault-tolerant network.
4. Supports 10/100Mbps or 10/100/1000Mbps full/half duplex self-adaptive transmission and auto-negotiations ,easy upgrades.
5. Max.transmission distance can be 120km.
6. External power or Built-in power.
7. Standalone type can be installed into 14slot 2U Rack; Card type into 16slot Rack.
8. Hot-swap ,High reliability.
9. Cache capacity: 1M Bits.
10. Built-in MAC address buffer space : 1K. Standards Protocol IEEE802.3 Ethernet standard IEEE802.3u fast Ethernet standard IEEE802.3d Spanning Tree standard
Ask Question About Product
Fiber Media Converter | |
Model | MC-G1E1SN |
Product Name | 10/100/1000M Media Converter |
Transmission Type | Gigabit Ethernet |
Transmission Mode | 10/100/1000M Full/half duplex |
MTBF | > 3 years |
BER | <1E-8 |
Data Buffer | 1MBits |
Power Stability Factor | 1MBits |
Input Power Range(dBm) | 0~-40 |
Operation Temperature | 0℃~70℃ |
Storage Temperature | -45℃~80℃ |
Maximum Current | 800mA |
Power | 2.5w |
EMC | Accord with FCC Part15 |
Volume | External: L×W×H 95×70×26mm Internal: L×W×H 140×110×30mm |
